What this code means
B1276 may indicate that the MICU is seeing an unexpected headlight switch position signal from the combination light switch circuit.
What the vehicle may do
- Exterior lights may not match the selected switch position.
- The code may appear during a body electrical scan even if the concern is intermittent.
- Lighting behavior can change if a switch input, wiring path, or ground path is not being read correctly.
Possible fault areas
- Possible combination light switch concern.
- Possible switch signal wiring concern.
- Possible switch ground path concern.
- Possible loose or poor connection.
- Possible MICU or under-dash fuse and relay box area concern.
Diagnostic path
Opening context
On this Accord, B1276 points us into the headlight switch position circuit as seen by the MICU. In plain language, the control unit may not be seeing the combination light switch state it expects. The driver may notice exterior lighting behavior that does not match the switch position, or the code may show up during a body electrical scan. The possible fault areas are the combination light switch, the switch signal wiring, the switch ground path, poor connections, or the MICU area in the under-dash fuse and relay box. We’ll keep the related switch-position codes as background only and stay focused on the B1276 diagnostic path.
Start by verifying the switch data
Start with the basic system checks, then verify the problem in the scan tool data list. Watch the four headlight switch parameters while moving the combination light switch through OFF, POSITION or PARKING, AUTO, and ON or HEADLIGHT. In OFF, only the OFF parameter should read ON. In POSITION, only the PARKING parameter should read ON. In AUTO, only the AUTO parameter should read ON. In HEADLIGHT, PARKING and HEADLIGHT should read ON, while OFF and AUTO stay OFF. If every value follows the switch correctly, treat it as an intermittent failure for now. The system is OK at this time, so concentrate on loose terminals, poor connections, or a condition that is not present right now. If any value does not match, continue with the circuit checks.
Decide whether the signal is stuck ON or stuck OFF
Next, look at the same headlight switch data list values again: OFF, PARKING, AUTO, and HEADLIGHT. The decision here is simple. If the affected data value is OFF when it should not be ON, go to the jumper test at the switch connector. If the value is still showing ON, go after a possible switch input being held low or shorted.
If the data is stuck ON, isolate the switch from the circuit
For a value that is stuck ON, turn the ignition switch to LOCK (0), or put the vehicle in OFF mode with the engine start/stop button. Disconnect the combination light switch 12P connector, then check the same scan tool parameters again. If the value changes from ON to OFF after the switch is unplugged, the combination light switch is the failure area, and the procedure calls for replacing the combination light switch. If the value does not change, leave the switch disconnected and move on to checking the wiring for a short to ground.
Check the switch signal wires for a short to ground
With the ignition still at LOCK (0) or OFF mode, disconnect under-dash fuse/relay box connector N (20P). For this short-to-ground check, the combination light switch 12P connector and under-dash fuse/relay box connector N (20P) both stay disconnected. Check continuity to body ground on the H/L OFF SW, H/L ON SW, and PARKING LT SW circuits. That means connector N No. 18, PNK, to body ground; connector N No. 19, YEL, to body ground; and connector N No. 20, GRY, to body ground. If there is continuity on one of those circuits, repair the short to ground in that wire. If there is no continuity, those three switch signal wires are OK, and the procedure identifies a faulty MICU; replace the under-dash fuse/relay box.
If the data is stuck OFF, simulate the switch input
If the earlier data list check sent you down the OFF-side path, turn the ignition switch to LOCK (0), or select OFF mode, and disconnect the combination light switch 12P connector. Now use a jumper wire to connect each switch input to body ground as called out: connector No. 1, PNK, to body ground; connector No. 7, YEL, to body ground; and connector No. 8, GRY, to body ground. Watch the same scan tool parameters while you do it. If the value changes from OFF to ON, the wiring and MICU are seeing the input, so the procedure calls for replacing the combination light switch. If the value does not change from OFF to ON, continue to the open or high-resistance checks.
Check for opens or high resistance
For the open-circuit check, keep the ignition at LOCK (0) or OFF mode. Disconnect under-dash fuse/relay box connector N (20P), and keep the combination light switch 12P connector disconnected. Check continuity end to end on the H/L OFF SW, H/L ON SW, PARKING LT SW, and COMBI SW GND (LT) circuits. Check connector N No. 18, PNK, to combination light switch connector No. 1, PNK. Check connector N No. 19, YEL, to combination light switch connector No. 7, YEL. Check connector N No. 20, GRY, to combination light switch connector No. 8, GRY. Then check connector N No. 1, BLK, to combination light switch connector No. 6, BLK. If there is no continuity, repair the open or high resistance in the affected wire. If there is continuity on these circuits, the wires are OK and the MICU is the remaining suspect. At that final YES result, the replacement line is incomplete, so do not guess past it; pause, recheck the earlier diagnostic path, and avoid making an unsupported call.
Verify the result
After the repair, keep verification separate from the pinpoint testing. Clear the code, operate the combination light switch through the same positions, and confirm the scan tool data matches the switch positions and B1276 stays gone. The takeaway is to let the data list tell you whether the input is stuck ON or stuck OFF, then prove the switch, the signal wires, the ground path, and only then the MICU side. For more diagnostic training, visit stepdiagnostics.com.
