What this code means
B1648 may indicate that the keyless access control unit is seeing a possible problem in the front passenger door antenna circuit.
What the vehicle may do
- The vehicle may have intermittent keyless access response near the front passenger door.
- One-push start or smart key recognition can feel inconsistent depending on where the key is located.
- The concern may be intermittent if a connector or harness condition changes with door movement.
Possible fault areas
- Front passenger door outer handle antenna circuit
- EXT_FR_AS plus and minus wiring
- Loose or poor connector contact
- Keyless access control unit
Diagnostic path
Opening context
On this 2010 to 2015 Honda Civic with the 1.8 gas engine, B1648 points us toward the keyless access control unit side of the system. In plain terms, the car may not be seeing the front passenger door antenna circuit the way it expects to. A driver may notice keyless access or one-push start behavior that feels inconsistent around that side of the vehicle. The possible fault areas can include the front passenger door outer handle antenna, the EXT_FR_AS plus and minus wiring, connector condition, or the keyless access control unit itself. The goal here is not to guess at parts. We are going to confirm the code, command the circuit, then prove whether the wiring can carry the signal.
Confirm the code before testing
Start by clearing the codes with the HDS. Then go into the one-push start system menu, select the keyless access control unit, and enter self check. Run the self check, then check codes again with the HDS. If B1648 is indicated again, continue with the circuit test. If it is not indicated, treat this as an intermittent failure for now. The system is OK at this time, so concentrate on loose or poor connections rather than forcing a parts call.
Check keyless access control unit output on the front passenger antenna lines
For the output check, press the engine start/stop button to select OFF mode. Disconnect the front passenger's door outer handle 8P connector. Then press the engine start/stop button again to select ON mode. With the HDS, go back into keyless access control from the one-push start system menu and enter functional tests. Connect the voltmeter between the front passenger's door outer handle 8P connector No. 2, the GRN wire, and No. 6, the BLU wire. Now select FRONT PASSENGER (DOOR) ANTENNA L DC OUTPUT with the HDS. At this point, you are only answering one question: is there voltage or not. If voltage is present, the front passenger door LF antenna is faulty, and the repair path is to replace the front passenger's door outer handle. If there is no voltage, keep going and check the two antenna lines for an open or high resistance.
Check the EXT_FR_AS wiring for continuity
Next, press the engine start/stop button to select OFF mode. Disconnect keyless access control unit connector A, which is the 32P connector. With the front passenger's door outer handle 8P connector still disconnected and the keyless access control unit connector A disconnected, check continuity through each antenna line. For EXT_FR_AS plus, check from keyless access control unit connector A (32P) No. 22, GRN, to front passenger's door outer handle 8P connector No. 2, GRN. For EXT_FR_AS minus, check from keyless access control unit connector A (32P) No. 6, BLU, to front passenger's door outer handle 8P connector No. 6, BLU. If both wires have continuity, the EXT_FR_AS plus and minus wires are OK, and the diagnostic path calls for replacing the keyless access control unit. If continuity is not present, repair the open or high resistance in the wire.
Wrap-up and verification mindset
Keep the verification separate from the circuit testing. First prove whether B1648 returns after clearing and self check. Then prove whether the control unit can produce output at the passenger handle connector. If it cannot, prove the two wires end to end before making the control unit call. The takeaway is simple: confirm the code, command the antenna output, then let the wiring test decide whether this is an antenna, harness, or control unit path. For more diagnostic training, visit stepdiagnostics.com.
Final check
B1648 is best approached by confirming the code, commanding the passenger antenna output, and then checking the antenna wiring before deciding which fault path is supported.
