What this code means
P0341 may mean the PCM is seeing a camshaft timing signal or camshaft timing relationship that is outside what it expects for the VTC system.
What the vehicle may do
- The vehicle may run normally when the fault is intermittent.
- The vehicle may show a drivability complaint when the fault is active.
- The check engine light may be on with the code stored or pending.
Possible fault areas
- Possible VTC oil control issue
- Possible camshaft timing issue
- Possible cam chain damage or stretch
- Possible VTC actuator issue
- Possible poor connection or loose terminal condition
Diagnostic path
Opening context
On this 2010 through 2016 Honda CR-V with the 2.4 gas engine, P0341 may mean the PCM is seeing a cam timing signal or cam timing relationship that does not look right for the VTC system. The vehicle may run normally at times, or it may have an intermittent drivability complaint when the fault shows up. The broad areas to keep in mind are VTC oil control, camshaft timing, cam chain condition, VTC actuator operation, and connector or terminal condition. Before getting deep into the test path, start with the basic system checks so you are not chasing a code with a basic setup or connection issue still unresolved.
Duplicate the fault first
Start by verifying the problem. Turn the vehicle to the ON mode, clear the DTC with the HDS, then test-drive at a steady speed between 19－38 mph (30－60 km/h) for 10 minutes. After that, check for Pending or Confirmed DTCs with the HDS. If P0341 comes right back, the failure is duplicated, and the path moves to the VTC oil control valve operation check. If P0341 does not show up, keep going with the VTC system checks instead of jumping to parts.
Use the VTC checks to decide if the monitor can fail
Next, run the VTC TEST from the HDS inspection menu. If that test is not OK, move to the VTC oil control valve operation check. If it is OK, test-drive again at a steady speed between 19－38 mph (30－60 km/h) for 10 minutes, then watch VTC STATUS on the HDS. The expected status for this check is ON. If the current condition does not match that status, repeat the test-drive and recheck VTC STATUS. If it does match, monitor the OBD STATUS for P0341 in the HDS DTC menu. If the HDS shows FAILED, continue to the VTC oil control valve check. If it shows PASSED, treat it as an intermittent failure and try to duplicate it under the same captured conditions if those conditions are available. If the status shows NOT COMPLETED, the return point in the path is not clear, so pause, recheck the earlier diagnostic path, and avoid guessing.
Work through the VTC and mechanical checks in order
Once the path sends you into testing, check the VTC oil control valve operation. If the valve is not OK, replace the VTC oil control solenoid valve. If the valve is OK, check camshaft timing. If camshaft timing is not OK, reset the camshaft timing. If camshaft timing is OK, check the cam chain for damage or stretch. If the cam chain is damaged or stretched, replace the cam chain and the auto-tensioner. If the chain is not damaged or stretched, inspect the VTC actuator. If the actuator is not OK, replace the VTC actuator. If the actuator checks OK, move on to the final PGM-FI system check.
Verify the repair and confirm the code stays gone
For the final check, turn the vehicle to the ON mode, reset the PCM with the HDS, do the CKP pattern clear procedure, do the PCM idle learn procedure, and then do the CKP pattern learn procedure. After that, test-drive at a steady speed between 19－38 mph (30－60 km/h) for 10 minutes and check again for Pending or Confirmed DTCs with the HDS. If P0341 is indicated, check for poor connections or loose terminals at the VTC oil control solenoid valve and the PCM, then go back to the beginning and verify the problem again. If P0341 is not indicated, treat it as an intermittent failure, and if captured conditions are available, try to reproduce the failure under those same conditions.
Takeaway
The key on P0341 is to prove whether the monitor can actually fail, then follow the VTC oil control, cam timing, chain, actuator, and connection checks in order. Do not skip straight to a part when the code may only be intermittent. For more diagnostic training, visit stepdiagnostics.com.
Final check
P0341 is handled by verifying the fault first, then checking the VTC and mechanical timing path in order before final confirmation.
