What this code means
B1237 may indicate the climate control unit is seeing an unexpected passenger air mix motor feedback signal condition in the HVAC system.
What the vehicle may do
- The passenger side temperature may not change correctly.
- The air coming from the passenger side vents may not match the selected temperature.
- The HVAC system may have limited or incorrect passenger side blend door control.
Possible fault areas
- Passenger's air mix control motor area
- S5V supply and feedback circuit area
- HVAC connector or wiring condition
- Climate control unit area
Diagnostic path
Open and diagnostic focus
On this 2017 to 2025 Honda CR-V with the 1.5 turbo engine, B1237 points to a passenger's air mix control motor circuit short in the HVAC system. In plain terms, the climate control unit may be seeing the passenger air mix motor feedback lower than it expects. The customer may notice the passenger side temperature does not respond correctly, or the HVAC output may not match the command. The broad fault areas can include the passenger's air mix control motor, its S5V and feedback circuits, connector condition, or the climate control unit. If other short-circuit codes are present at the same time, check what those codes mean first, because the S5V circuit may have an open or a short to body ground.
Start with confirmation
Start with the basic system checks and follow a structured diagnostic approach before getting into pinpoint testing. Then turn the vehicle to the ON mode and confirm the fault. Use the HDS Body Electrical, HVAC, Data List information as supporting data while you watch what the system is doing.
Passenger's air mix control motor output check
Next, move to the passenger's air mix control motor side. Disconnect the passenger's air mix control motor connector, the 5P connector. With IG Mode ON, perform the listed checks at the disconnected 5P female terminals. The normal unit output voltage for each listed ON row is About 5 V. There is not a direct standalone test for the motor itself here, so the diagnosis works through the related outputs and circuits. If this check is normal, the fault points to a problem with the passenger's air mix control motor. If it is abnormal, keep going because the problem is in another related area.
S5V and AMD-P-AS circuit check
After that, check the S5V and AMD-P-AS circuits. Disconnect the passenger's air mix control motor 5P connector, and also disconnect climate control unit connector B, the 24P connector. With IG Mode OFF, perform the circuit checks between the disconnected connector terminals. For the S5V open-wire check, normal is less than 1 Ω. For the S5V short-to-ground check, normal is Not shorted. For the AMD-P-AS short-to-ground check, normal is more than 1 MΩ. For the shorted-circuit portion, use the open and shorted wire inspection method and inspect based on the circuit condition you find. If this circuit check is abnormal, the fault is in the circuit.
Climate control unit check
Only move into the climate control unit check with the external circuit normal. There is a note that this check can be done early because it includes the listed inspection items, but if it fails, do not stop there; continue the individual checks to find which item failed. For this check, disconnect the passenger's air mix control motor 5P connector. Leave climate control unit connector B, the 24P connector, connected. With IG Mode ON, perform the internal circuit checks at the climate control unit connector B female terminals. The normal condition for each listed ON row is About 5 V. If this check is abnormal, the fault points to a problem with the climate control unit.
Takeaway
The clean way to handle B1237 is to separate the motor output check from the S5V and feedback circuit checks, and only judge the climate control unit after the external circuit has checked normal. For more diagnostic training, visit stepdiagnostics.com.
Final check
B1237 is often approached by checking the passenger air mix motor output, then the related S5V and feedback circuits, before considering the climate control unit.
