What this code means
P0706 may mean the control module is not seeing the expected transmission range switch signal for the selected gear range.
What the vehicle may do
- The vehicle may not recognize the selected range correctly.
- Scan data may not match the shifter position.
- Shift-related operation can be affected when range information is missing or incorrect.
Possible fault areas
- Possible shift cable adjustment issue.
- Possible transmission range switch signal circuit issue.
- Possible connector or wiring issue.
- Possible related ground path issue.
- Possible ICM involvement after circuit checks are normal.
Diagnostic path
Open and code meaning
On this Accord Hybrid, P0706 is pointing at a transmission range switch open-type fault. In plain terms, the ICM may not be seeing the Forward Switch signal when the shifter is commanded into Drive. The vehicle may have shift-position recognition problems, or the scan data may not agree with the selected range. The possible fault areas are the shift cable adjustment, the transmission range switch signal path, the related ground path, connector or wiring issues, and, if the rest of the circuit checks good, the ICM itself.
Start with the basic checks
Before jumping into pinpoint testing, start with the basic system checks and follow a structured diagnostic approach. Then make sure the shift cable is properly adjusted. If the cable is off, the range switch and scan data can lead you in the wrong direction, so handle that first.
Duplicate the fault with scan data
Turn the vehicle to ON mode. Press the brake pedal, then shift the transmission to D position or D mode. Now watch the HDS Forward Switch, labeled ATPFWD. If ATPFWD shows OFF while the transmission is in D position or mode, the failure is duplicated and you move into circuit testing.
Set up the open-wire checks
With the failure duplicated, disconnect the transmission range switch 16P connector. Then disconnect ICM connector A, the 28P connector. At this stage, be certain you are on the correct ATPFWD and PG circuits before measuring. If you cannot positively identify the circuit points, pause and do not guess.
Check ATPFWD and PG for an open
Perform the ATP-FWD, or ATPFWD, open-wire inspection with both connectors disconnected. The normal condition is less than 1 Ω. Then perform the PG open-wire inspection the same way. That normal condition is also less than 1 Ω. If either inspection is abnormal, the diagnostic direction is a problem in the circuit.
If the circuit checks normal
If the other inspection items show normal, the diagnostic path moves to the ICM inspection determination. At that point, with the circuit checks normal, the remaining diagnostic result is a problem with the ICM. Do not turn that into a parts call until the earlier path has been followed cleanly and the test points are confirmed.
Takeaway and close
The key on P0706 is to prove the Forward Switch signal problem in Drive, verify the shift cable adjustment, then separate a circuit fault from an ICM-side fault with the open-wire checks. Keep the confirmation step separate from the circuit testing, and do not guess on connector points. For more diagnostic training, visit stepdiagnostics.com.
Final check
P0706 often comes down to confirming whether the Forward Switch signal is missing because of adjustment, wiring, or module-side input logic.
