What this code means
P2199 may indicate that the ECM/PCM sees the intake air temperature sensor readings as not agreeing with each other.
What the vehicle may do
- The vehicle may turn on the check engine light.
- Drivability can often seem normal, but symptoms may vary with the fault.
Possible fault areas
- Possible intake air temperature sensor input concern
- Possible connector or terminal concern
- Possible related temperature-sensor circuit or signal concern
Diagnostic path
Open
On this Accord Hybrid, P2199 is an ECM/PCM code that may point to an intake air temperature sensor correlation problem. In plain language, the computer is comparing the intake air temperature readings, and if the difference after startup is significant, it can flag the code. The vehicle may have a check engine light, and drivability may be normal or slightly off depending on the fault. Broadly, think about possible sensor input issues, connector or terminal problems, or a fault in the intake air temperature sensing path. Before digging in, start with the basic system checks and follow a structured diagnostic approach so you are not chasing this code out of order.
Monitor logic
The logic for P2199 is centered on the relationship between IAT sensor 1 and IAT sensor 2. After the engine is started, if the temperature difference between those two readings is significant, the PCM determines there is an abnormality and stores the DTC. Do not turn “significant” into a made-up temperature number. Treat this as a comparison fault and work the path in order.
Reproduce the operating conditions
First, turn the vehicle to the OFF, LOCK mode, and leave the vehicle for at least 6 hours. That soak time matters because this diagnostic depends on comparing temperature readings after the vehicle has been sitting. After the soak, enter maintenance mode, start the engine, and let it idle for at least 10 seconds.
Connector and terminal check
Next, check the related sensor connectors and terminals. Make sure the connections are secure and look for loose terminals at ECT sensor 1, ECT sensor 2, the MAF sensor with IAT sensor 1, and IAT sensor 2. If that check is abnormal, the diagnostic direction is a connection or terminal problem. If the connector and terminal check is normal, the diagnostic direction is a problem with IAT sensor 2.
Close
The takeaway on P2199 is simple: give the vehicle the required cold soak, reproduce the startup condition, then separate a connection or terminal issue from an IAT sensor 2 fault path without inventing a temperature threshold. After the fault path is handled, verify the repair and confirm the code stays gone. For more diagnostic training, visit stepdiagnostics.com.
Final check
Work it as a sensor-correlation fault: reproduce the required startup condition, check the related connections, and avoid assuming a temperature threshold that is not provided.
